Custom Sizes Thickness Vacuum Coated AR Anti Reflective Cover Glass with Ultra-Low Reflectance 1% for LCD Touchscreen Display
Elevate display clarity and readability with our premium vacuum-coated AR (Anti-Reflective) cover glass. Engineered specifically for LCD and touchscreen applications, this optical-grade glass delivers ultra-low surface reflectance of ≤1% (premium multi-layer options reach <0.5%), significantly reducing glare, ghosting, and ambient light interference while maximizing visible light transmittance (typically >98% for double-sided coating).
Manufactured using advanced vacuum magnetron sputtering / multi-layer dielectric deposition technology, alternating high- and low-index materials create destructive interference that cancels reflections across the visible spectrum (approx. 400–700 nm). The result is sharper contrast, richer colors, and superior outdoor or high-ambient-light performance compared to standard float glass (which reflects ~4% per surface / ~8% total).
Key Features & Benefits
- Ultra-Low Reflectance ≤1% — Dramatically improves screen visibility under bright light, sunlight, or indoor lighting. Reduces eye strain and enhances user experience.
- High Transmittance — Typically >95–98%+ (depending on single- or double-sided coating and substrate), preserving original display brightness and color accuracy.
- Fully Customizable — Exact sizes, thicknesses (common range 0.5–6 mm or more), shapes (rectangle, round, irregular, with holes/cutouts), edge treatments (C-edge, flat, beveled, polished), and optional black border silk-screen printing.
- Durable Vacuum Coating — Multi-layer optical coatings with excellent adhesion, hardness (often ≥5–9H), and environmental stability. Optional combination with AF (anti-fingerprint/oleophobic) or AG (anti-glare) coatings available.
- Substrate Options — Soda-lime, ultra-clear low-iron, chemically strengthened aluminosilicate, or other optical glasses for strength and optical performance.
- Compatible with Touch Technologies — Suitable for projected capacitive (PCAP), resistive, and other touch solutions; can be optically bonded or used as protective cover lens.
Parameters of AR glass
| Parameters | Ordinary glass | One side AR glass | Double sides AR glass |
| Color | Clear | Blue-purple | Natural color |
| Optical curve | / | V | W |
| Transmittance | ≤89% | ≥93% | ≥98% |
| Reflection | ≥8.4% | ≤5.2% | ≤1% |
| Application | Low-end product | Mid-range display panel | High-end display panel |
| Hardness | ≥7H | ≥7H | ≥7H |
| High temperature resistance | / | Fully tempered or semi-tempered at 650 degrees, AR coating layer no change. | |
Technical Specifications
| Substrate Materials | Soda-Lime Glass, Aluminosilicate Glass, Low-Iron Glass |
| Coating Technology | Vacuum Magnetron Sputtering / PVD AR |
| Optional Features | AF, AG, ITO, printing, tempering/chemical strengthening |
| Reflectance (Single Side) | ≤1% |
| Reflectance (Double Side) | ≤0.5% |
| Light Transmittance | ≥98% (peak up to 99%) |
| Hardness | ≥7H |
| Wavelength Range | Broadband visible (400–700 nm optimized) |
| Temperature Resistance | >500°C |
| Customization | Size, Shape, Thickness, Edge Finishing, Silk-Screen Printing |
Ideal Applications
- LCD / OLED / LED touchscreen displays and cover lenses
- Industrial HMI panels, medical monitors, and outdoor kiosks
- Automotive displays and instrument clusters
- Consumer electronics, tablets, interactive signage
- Optical instruments, sensor windows, and high-clarity protective covers
Why Choose Our AR Cover Glass?
Standard glass reflects significant light, washing out images and reducing contrast. Our vacuum-coated AR solution solves this at the source through precise thin-film interference, delivering professional-grade optical performance tailored to your exact dimensions and thickness needs. Whether you require single-side AR for bonded assemblies or double-side AR for free-standing covers, we support flexible MOQs and engineering collaboration.
Company Introduction
Founded in 2012, Fuxin Glass is a leading manufacturer specializing in the research, development, production, and export of cover glass, headquartered in Dongguan, China, near the ports of Shenzhen and Guangzhou.
With 13 years of industry experience, Fuxin serves customers in over 80 countries worldwide. With ISO/RoHS/JIS Z certifications, Fuxin Glass is dedicated to providing high-quality glass solutions for electronic displays and smart devices. Its products are widely used in interactive display, automotive electronics, industrial equipment, medical devices, home appliances, and smart devices. The products feature high light transmittance (over 95%), high hardness (Mohs 6), and excellent scratch and impact resistance. The 21,000-square-meter factory is equipped with four fully automated production lines, with a monthly production capacity of 300,000 pcs. We support small-batch trial production and large-scale delivery, and provide one-step technical support and after-sales service. Multi-dimensional customization is supported as well: including but not limited to mold design (samples can be produced in as fast as 7 days), special optical processing (AR/AF/AG/AM combination), explosion-proof structure design (multi-layer composite structure), color customization (7 colors are optional), silk screen logo, etc., to meet the personalized needs of customers. Our products have successfully entered mainstream markets such as North America, Japan, South Korea, India, and Europe, and widely serve interactive ( such us all in one machine, IFPD, smart white board ), automotive central control screens, industrial HMI, smart home panels and other fields.
We always adhere to the principle of "integrity, quality and win-win" and are willing to establish good long-term cooperative relationships with customers all over the world!
Partial Sample Display
Factory Overview
Inspection Progress
Certification
Package
Delivery & Lead Time
| Original Country | China |
| FOB Port | Shenzhen or Hongkong |
| HS Code | 700719000 |
| Lead Time | Sample within 7 days, bulk order 15~20 days |
| Delivery | By sea / DHL / Fedex / UPS |
Payment Details
1. Soda-lime Glass (Ordinary Flat Glass)
- Composition: Mainly composed of silicon dioxide (SiO₂, approximately 70%), sodium oxide (Na₂O), and calcium oxide (CaO).
- Characteristics: Easy to produce, low cost, but poor thermal stability and brittle.
- Applications: The most common type of glass, used for doors, windows, bottles, jars, and everyday utensils.
2. Borosilicate Glass (Heat-Resistant Glass)
- Composition: Based on soda-lime glass, boron oxide (B₂O₃) is added.
- Characteristics: Low coefficient of thermal expansion, high temperature resistance, resistance to rapid temperature changes (not easily cracked by sudden heating and cooling), good chemical stability.
- Applications: Laboratory instruments (such as beakers and test tubes), heat-resistant tableware (such as baking pans and glass pots), high-end flashlight lenses, etc. Well-known brands include Pyrex.
3. Aluminosilicate Glass
- Composition: Contains a large amount of aluminum oxide (Al₂O₃) and silicon dioxide (SiO₂).
- Characteristics: High hardness, scratch resistance, high mechanical strength, superior performance compared to borosilicate glass.
- Applications: Cover glass for high-end mobile phones/tablets, aviation glass, etc. Well-known brands include Corning Gorilla Glass.
4. Quartz Glass
- Composition: Silicon dioxide (SiO₂) content is above 99%.
- Characteristics: Excellent heat resistance (softening point up to 1700℃), wide light transmission spectrum (from ultraviolet to infrared), high purity, and excellent chemical stability. However, it is expensive.
- Applications: Semiconductor industry, optical devices, observation windows in high-temperature furnaces, ultraviolet lamps, etc.
To get an accurate quotation, please provide (if available):
- Product dimensions & glass thickness
- Application / usage
- Edge grinding type
- Surface treatment (coating - AG/AR/AF/AM or overlay, printing, etc.)
- Packaging requirements
- Quantity or annual usage
- Required delivery time
- Drilling or special hole requirements
- Drawings or photos
If you don't have all the details yet: just provide the information you have. Our team can discuss your requirements and help you determine specifications or suggest suitable options.
-
1
1) Are you a trading company or manufacturer?
1. Leading glass deep processing factory
2. 13 years of experience
3. OEM/ODM expertise -
2
2) How to order?
1. Your detailed requirements: drawings/quantity/or your special requirements.
2. Let's get to know each other better: We can provide your requirements.
3. Email us your formal order, payment.
4. We will incorporate the order into our mass production plan and produce according to the approved sample.
5. Packing & shipping -
3
3) Do you provide samples for testing?
We can provide free samples, but the shipping cost will be borne by the customer.
-
4
4) What is your minimum order quantity?
A: 200 pieces.
-
5
5) How long does a sample order take? How about a bulk order?
Sample order: Usually within a week.
Bulk order: Usually takes 15~20 days depending on quantity and design. -
6
6) What packaging do the products use?
Plastic wrap + pearl cotton + kraft paper + cartoon box + wooden crate.
-
7
7) How do you ship the goods, and how long does it take to arrive?
We usually ship by sea / air freight/ International Express, and the arrival time depends on the distance.
-
8
8) What are your payment terms?
A: T/T 100% in advance, or other payment methods.
-
9
9) Do you provide OEM/ODM services?
Yes, we can customize.
-
9
10) Do your products have certificates?
Yes, we have ISO9001/REACH/RoSH/GS/JIS Z certifications.
