Bespoke Thickness 0.5–3.0mm AG Anti Glare Coated Glass with AM Antibacterial Coating for Touchscreen
Upgrade your touchscreen displays with precision-engineered cover glass that combines superior optical performance, glare control, and lasting surface hygiene. Our bespoke AG (Anti-Glare) glass features a durable micro-textured surface treatment paired with an advanced AM (Antimicrobial/Antibacterial) coating, available in any thickness from 0.5 mm to 3.0 mm to match your exact mechanical and optical requirements.
Key Features
- Custom Thickness Range: 0.5 mm – 3.0 mm (precise control for slim consumer devices up to robust industrial panels).
- AG Anti-Glare Treatment: Micro-etched or coated surface that diffuses ambient light, converting harsh specular reflections into soft diffuse reflection. Typical haze 5–25% (tunable), transmittance typically ≥89%, excellent readability under strong indoor lighting or outdoor conditions.
- AM Antibacterial Coating: High-efficiency antimicrobial layer that inhibits bacterial growth (commonly tested against E. coli and S. aureus to >99% efficacy standards). Transparent, optically neutral, and durable for frequent-touch environments.
- Smooth Touch Feel: Matte yet tactile surface optimized for capacitive touchscreens while reducing fingerprint visibility.
- High Durability Options: Compatible with chemical strengthening, tempering, edge processing, CNC cutting, drilling, printing, and optional AF (anti-fingerprint) top layers.
- Full Customization: Size, shape, edge finish (C-edge, chamfer, polished), holes, notches, silk-screen printing, and coating combinations (AG + AM, AG + AF + AM, etc.).
- Superior optical performance even in high-glare environments
- Enhanced touch sensitivity compatibility (works seamlessly with capacitive and resistive touch sensors)
- Excellent scratch resistance and chemical durability
- Reduced maintenance thanks to AF coating
- Premium visual experience that matches high-end smart home and industrial aesthetics
- Lightweight design for easier assembly and lower shipping costs
Technical Specifications
| Thickness |
0.5 – 3.0 mm (custom)
|
| Material |
Soda-lime or aluminosilicate (optional)
|
|
Surface Treatment
|
AG Anti-Glare Etched
|
|
Optional Coatings
|
AR (Anti-Reflective) / AF (Anti-Fingerprint)/AM anti microbial
|
| Transmittance |
≥90% (with AR)
|
|
Haze
|
Controlled for optimal anti-glare
|
| Hardness |
≥6H
|
|
Customization
|
Size, shape, printing, holes, edges
|
|
Applications
|
Smart control panels, HMI, touch interfaces, home automation, industrial panels
|
Ideal Applications
- Industrial HMI and control panels
- Medical and diagnostic touchscreens
- Outdoor and semi-outdoor kiosks / terminals
- Commercial POS, access control, and public information displays
- Automotive and transportation interfaces
- High-hygiene environments (healthcare, food service, shared devices)
Why Choose Our Bespoke AG + AM Glass?
Fuxin Glass specializes in application-driven customization. Whether you need ultra-thin 0.5–0.7 mm glass for compact devices or thicker 2.0–3.0 mm panels for rugged industrial use, we match haze level, coating stack, strength treatment, and dimensional tolerances to your lighting conditions, touch frequency, cleaning protocols, and mechanical constraints. Low MOQ sampling, rapid prototyping, and consistent batch-to-batch optical performance are standard.
FAQs
1. What is AG anti-glare coated glass and how does it work on touchscreens?
AG (anti-glare) coating creates a fine micro-texture on the glass surface that scatters ambient light instead of reflecting it like a mirror. This reduces harsh glare, improves readability in bright environments, and makes touchscreen content clearer without significantly affecting image quality.
2. What does the AM antibacterial coating do?
The AM (antimicrobial/antibacterial) coating actively inhibits the growth of bacteria on the glass surface. It helps maintain a more hygienic touchscreen, especially useful in medical, public, industrial, and high-touch environments, while remaining optically clear and durable.
3. Can the glass thickness be customized between 0.5 mm and 3.0 mm?
Yes. We offer fully bespoke thickness options from 0.5 mm to 3.0 mm to match your device design, mechanical strength needs, and optical requirements. Custom sizes, shapes, and edge finishes are also available.
4. What applications is this AG + AM coated glass best suited for?
It is ideal for industrial HMI panels, medical displays, outdoor and indoor kiosks, commercial touch terminals, access control systems, and any high-touch or bright-light environment where glare reduction and surface hygiene are important.
5. Is the anti-glare and antibacterial coating durable and easy to clean?
Yes. The AG treatment is a permanent surface modification, and the AM coating is designed for long-term performance under normal cleaning. The glass can be wiped with standard mild cleaners and is compatible with chemical strengthening for added scratch and impact resistance.
Company Introduction
Founded in 2012, Fuxin Glass is a leading manufacturer specializing in the research, development, production, and export of cover glass, headquartered in Dongguan, China, near the ports of Shenzhen and Guangzhou.
With 13 years of industry experience, Fuxin serves customers in over 80 countries worldwide. With ISO/RoHS/JIS Z certifications, Fuxin Glass is dedicated to providing high-quality glass solutions for electronic displays and smart devices. Its products are widely used in interactive display, automotive electronics, industrial equipment, medical devices, home appliances, and smart devices. The products feature high light transmittance (over 95%), high hardness (Mohs 6), and excellent scratch and impact resistance. The 21,000-square-meter factory is equipped with four fully automated production lines, with a monthly production capacity of 300,000 pcs. We support small-batch trial production and large-scale delivery, and provide one-step technical support and after-sales service. Multi-dimensional customization is supported as well: including but not limited to mold design (samples can be produced in as fast as 7 days), special optical processing (AR/AF/AG/AM combination), explosion-proof structure design (multi-layer composite structure), color customization (7 colors are optional), silk screen logo, etc., to meet the personalized needs of customers. Our products have successfully entered mainstream markets such as North America, Japan, South Korea, India, and Europe, and widely serve interactive ( such us all in one machine, IFPD, smart white board ), automotive central control screens, industrial HMI, smart home panels and other fields.
We always adhere to the principle of "integrity, quality and win-win" and are willing to establish good long-term cooperative relationships with customers all over the world!
Partial Sample Display
Certification
Factory Overview
Inspection Progress
Package
Delivery & Lead Time
| Original Country | China |
| FOB Port | Shenzhen or Hongkong |
| HS Code | 700719000 |
| Lead Time | Sample within 7 days, bulk order 15~20 days |
| Delivery | By sea / DHL / Fedex / UPS |
Payment Details
1. Soda-lime Glass (Ordinary Flat Glass)
- Composition: Mainly composed of silicon dioxide (SiO₂, approximately 70%), sodium oxide (Na₂O), and calcium oxide (CaO).
- Characteristics: Easy to produce, low cost, but poor thermal stability and brittle.
- Applications: The most common type of glass, used for doors, windows, bottles, jars, and everyday utensils.
2. Borosilicate Glass (Heat-Resistant Glass)
- Composition: Based on soda-lime glass, boron oxide (B₂O₃) is added.
- Characteristics: Low coefficient of thermal expansion, high temperature resistance, resistance to rapid temperature changes (not easily cracked by sudden heating and cooling), good chemical stability.
- Applications: Laboratory instruments (such as beakers and test tubes), heat-resistant tableware (such as baking pans and glass pots), high-end flashlight lenses, etc. Well-known brands include Pyrex.
3. Aluminosilicate Glass
- Composition: Contains a large amount of aluminum oxide (Al₂O₃) and silicon dioxide (SiO₂).
- Characteristics: High hardness, scratch resistance, high mechanical strength, superior performance compared to borosilicate glass.
- Applications: Cover glass for high-end mobile phones/tablets, aviation glass, etc. Well-known brands include Corning Gorilla Glass.
4. Quartz Glass
- Composition: Silicon dioxide (SiO₂) content is above 99%.
- Characteristics: Excellent heat resistance (softening point up to 1700℃), wide light transmission spectrum (from ultraviolet to infrared), high purity, and excellent chemical stability. However, it is expensive.
- Applications: Semiconductor industry, optical devices, observation windows in high-temperature furnaces, ultraviolet lamps, etc.
To get an accurate quotation, please provide (if available):
- Product dimensions & glass thickness
- Application / usage
- Edge grinding type
- Surface treatment (coating - AG/AR/AF/AM or overlay, printing, etc.)
- Packaging requirements
- Quantity or annual usage
- Required delivery time
- Drilling or special hole requirements
- Drawings or photos
If you don't have all the details yet: just provide the information you have. Our team can discuss your requirements and help you determine specifications or suggest suitable options.
-
1
1) Are you a trading company or manufacturer?
1. Leading glass deep processing factory
2. 13 years of experience
3. OEM/ODM expertise -
2
2) How to order?
1. Your detailed requirements: drawings/quantity/or your special requirements.
2. Let's get to know each other better: We can provide your requirements.
3. Email us your formal order, payment.
4. We will incorporate the order into our mass production plan and produce according to the approved sample.
5. Packing & shipping -
3
3) Do you provide samples for testing?
We can provide free samples, but the shipping cost will be borne by the customer.
-
4
4) What is your minimum order quantity?
A: 200 pieces.
-
5
5) How long does a sample order take? How about a bulk order?
Sample order: Usually within a week.
Bulk order: Usually takes 15~20 days depending on quantity and design. -
6
6) What packaging do the products use?
Plastic wrap + pearl cotton + kraft paper + cartoon box + wooden crate.
-
7
7) How do you ship the goods, and how long does it take to arrive?
We usually ship by sea / air freight/ International Express, and the arrival time depends on the distance.
-
8
8) What are your payment terms?
A: T/T 100% in advance, or other payment methods.
-
9
9) Do you provide OEM/ODM services?
Yes, we can customize.
-
9
10) Do your products have certificates?
Yes, we have ISO9001/REACH/RoSH/GS/JIS Z certifications.
