Factory Price Custom AG Touchscreen Glass for Electronic Appliance LCD Display with Silk Screen
Factory Price Custom AG Touchscreen Glass for Electronic Appliance LCD Display with Silk Screen
Key Features
-
Anti-Glare Surface Treatment: The AG coating minimizes surface reflections, improves readability in ambient light, and reduces eye strain – ideal for displays used in kitchens, outdoors, or brightly lit environments.
-
High Transparency & Clarity: Despite the anti-glare effect, the glass maintains excellent light transmission (typically >90%) to keep your LCD display vibrant and sharp.
-
Precision Silk Screen Printing: We apply custom silk screen patterns (borders, logos, icons, or decorative frames) with ±0.1mm tolerance, using durable ceramic or epoxy inks that resist fading and abrasion.
-
Touchscreen Optimized: The glass is compatible with capacitive and resistive touch sensors, providing smooth responsiveness and high sensitivity.
-
Durable & Scratch-Resistant: Chemically strengthened (optional) to resist impacts and scratches, ensuring long-lasting performance in demanding appliance environments.
-
Custom Sizes & Shapes: Available in any size from 1” to 55”+ with precision CNC cutting, edge grinding, and drilling to your specifications.
-
Oleophobic Coating Option: Add an anti-fingerprint layer to keep the surface clean and easy to wipe.
|
Material
|
High-quality soda-lime float glass
|
|
Thickness
|
0.4mm, 0.7mm, 1.0mm, 1.5mm, 2.0mm (±0.05mm tolerance)
|
|
Hardness
|
9H pencil hardness
|
|
Viewing Angles
|
>160° horizontal / >140° vertical
|
|
Surface Treatment
|
AG (Anti‑Glare), AF (Anti‑Fingerprint), AR (Anti‑Reflective), or combination
|
|
Gloss Level (60°)
|
60 - 130 GU (Typical ranges: 80±10, 100±10)
|
|
Haze
|
Typically ≤10% (Common range: 1%-9%)
|
|
Tempering
|
Fully tempered (safety glass standard)
|
|
Light Transmittance
|
≥ 92% (uncoated); ≥ 95% (with AR coating)
|
|
Operating Temperature
|
-20°C to +80°C
|
|
Glare Reduction
|
Up to 80% (depending on etching level)
|
|
Size
|
Fully customized (up to 32–86 inches)
|
|
Edge Processing
|
CNC grinding, chamfered, or polished
|
|
Customization
|
Size, shape, hole patterns, silk‑screen printing, logo printing
|
Customization Options
We understand that every appliance design is unique. That's why we offer full customization:
-
Dimensions: Cut to your exact size, with holes, notches, or curved edges.
-
Silk Screen Design: Upload your artwork (AI, CDR, DXF, CAD) and we'll replicate it precisely.
-
Glass Material: Choose from standard soda-lime or high-strength alumino-silicate for enhanced durability.
-
Coatings: Combine AG with anti-reflective (AR) or anti-fingerprint (AF) coatings for premium performance.
-
Printing Type: Single-sided or double-sided printing, with opaque or translucent inks.
Our AG/AF/AR coated tempered glass is trusted by manufacturers across industries:
-
Industrial Touch Panels: HMI interfaces, factory automation, and control systems.
-
Medical Devices: Patient monitors, diagnostic equipment, and handheld terminals.
-
Consumer Electronics: Smart home displays, tablets, GPS units, and wearables.
-
Retail & Kiosks: Point‑of‑sale systems, interactive kiosks, and vending machines.
-
Automotive Displays: Infotainment systems and dashboard touchscreens.
-
Outdoor Equipment: Terminals and devices exposed to bright sunlight (AG/AR coatings essential).
-
Manufacturing Excellence: As a leading factory with over a decade of experience, we operate 21,000+ square meters of facility with fully automated production lines, ensuring a monthly capacity of 300,000 pieces. Our commitment to quality is backed by ISO, RoHS, and CE certifications .
-
End-to-End Customization: From initial design and mold making (samples in ~7 days) to mass production, our engineering team works with you to develop the perfect solution, including complex hole patterns, multi-layer silk-screening, and combined optical coatings .
-
Rigorous Quality Assurance: Every batch undergoes stringent testing, including abrasion resistance (steel wool), environmental stability (boiling water), and optical performance checks, guaranteeing that the glass delivered meets the highest standards of durability and clarity .
-
Global Reach: Trusted by customers in over 80 countries, including North America, Europe, Japan, and South Korea, our glass is the preferred choice for global leaders in interactive technology.
| Process Name | Production capacity （55 inch） | Remark |
| Cutting | 10,000pcs/day | |
| Edging and Grinding | 3,000pcs/day | The production capacity calculated based on 55-inch |
|
Silk Screen Printing |
3,000pcs/day | The production capacity will change as the number of screen printing processes increases or decreases (the screen printing equipment is being expanded) |
|
Tempering |
2,800pcs/day | |
|
AG Spray Coating |
1,500pcs/day | |
|
Packaging |
3,500pcs/day |
Q: What is AG glass, and why is it important for appliance displays?
A: AG stands for anti-glare. It diffuses reflected light to reduce glare, making the screen easier to read in bright environments. This is crucial for appliances used in kitchens, outdoors, or under direct light.
Q: Can I combine AG treatment with silk screen printing?
A: Absolutely. We apply silk screen printing after the AG treatment (or on the opposite side) to ensure both functions work perfectly. The printing can be on the back surface for a flush look.
Q: What file formats do you accept for silk screen artwork?
A: We accept AI, CAD, CorelDRAW, DXF, PDF, and high-resolution PNG files. Our team can also help you convert your design.
Q: Do you offer samples before bulk order?
A: Yes, we provide prototypes for testing. Sample cost is reasonable and can be deducted from bulk order.
Q: What is the minimum order quantity (MOQ)?
A: MOQ for standard sizes is 100 pieces. For fully custom designs, MOQ may vary – please contact us for details.
Q: How do I get a quote?
A: Simply send us your requirements (size, thickness, quantity, artwork) via the form below or email us at yamy@fuxinag.com. We'll respond within 24 hours.
Company Introduction
Founded in 2012, Fuxin Glass is a leading manufacturer specializing in the research, development, production, and export of cover glass, headquartered in Dongguan, China, near the ports of Shenzhen and Guangzhou.
With 13 years of industry experience, Fuxin serves customers in over 80 countries worldwide. With ISO/RoHS/JIS Z certifications, Fuxin Glass is dedicated to providing high-quality glass solutions for electronic displays and smart devices. Its products are widely used in interactive display, automotive electronics, industrial equipment, medical devices, home appliances, and smart devices. The products feature high light transmittance (over 95%), high hardness (Mohs 6), and excellent scratch and impact resistance. The 21,000-square-meter factory is equipped with four fully automated production lines, with a monthly production capacity of 300,000 pcs. We support small-batch trial production and large-scale delivery, and provide one-step technical support and after-sales service. Multi-dimensional customization is supported as well: including but not limited to mold design (samples can be produced in as fast as 7 days), special optical processing (AR/AF/AG/AM combination), explosion-proof structure design (multi-layer composite structure), color customization (7 colors are optional), silk screen logo, etc., to meet the personalized needs of customers. Our products have successfully entered mainstream markets such as North America, Japan, South Korea, India, and Europe, and widely serve interactive ( such us all in one machine, IFPD, smart white board ), automotive central control screens, industrial HMI, smart home panels and other fields.
We always adhere to the principle of "integrity, quality and win-win" and are willing to establish good long-term cooperative relationships with customers all over the world!
Partial Sample Display
Certification
Factory Overview
Inspection Progress
Package
Delivery & Lead Time
| Original Country | China |
| FOB Port | Shenzhen or Hongkong |
| HS Code | 700719000 |
| Lead Time | Sample within 7 days, bulk order 15~20 days |
| Delivery | By sea / DHL / Fedex / UPS |
Payment Details
1. Soda-lime Glass (Ordinary Flat Glass)
- Composition: Mainly composed of silicon dioxide (SiO₂, approximately 70%), sodium oxide (Na₂O), and calcium oxide (CaO).
- Characteristics: Easy to produce, low cost, but poor thermal stability and brittle.
- Applications: The most common type of glass, used for doors, windows, bottles, jars, and everyday utensils.
2. Borosilicate Glass (Heat-Resistant Glass)
- Composition: Based on soda-lime glass, boron oxide (B₂O₃) is added.
- Characteristics: Low coefficient of thermal expansion, high temperature resistance, resistance to rapid temperature changes (not easily cracked by sudden heating and cooling), good chemical stability.
- Applications: Laboratory instruments (such as beakers and test tubes), heat-resistant tableware (such as baking pans and glass pots), high-end flashlight lenses, etc. Well-known brands include Pyrex.
3. Aluminosilicate Glass
- Composition: Contains a large amount of aluminum oxide (Al₂O₃) and silicon dioxide (SiO₂).
- Characteristics: High hardness, scratch resistance, high mechanical strength, superior performance compared to borosilicate glass.
- Applications: Cover glass for high-end mobile phones/tablets, aviation glass, etc. Well-known brands include Corning Gorilla Glass.
4. Quartz Glass
- Composition: Silicon dioxide (SiO₂) content is above 99%.
- Characteristics: Excellent heat resistance (softening point up to 1700℃), wide light transmission spectrum (from ultraviolet to infrared), high purity, and excellent chemical stability. However, it is expensive.
- Applications: Semiconductor industry, optical devices, observation windows in high-temperature furnaces, ultraviolet lamps, etc.
To get an accurate quotation, please provide (if available):
- Product dimensions & glass thickness
- Application / usage
- Edge grinding type
- Surface treatment (coating - AG/AR/AF/AM or overlay, printing, etc.)
- Packaging requirements
- Quantity or annual usage
- Required delivery time
- Drilling or special hole requirements
- Drawings or photos
If you don't have all the details yet: just provide the information you have. Our team can discuss your requirements and help you determine specifications or suggest suitable options.
-
1
1) Are you a trading company or manufacturer?
1. Leading glass deep processing factory
2. 13 years of experience
3. OEM/ODM expertise -
2
2) How to order?
1. Your detailed requirements: drawings/quantity/or your special requirements.
2. Let's get to know each other better: We can provide your requirements.
3. Email us your formal order, payment.
4. We will incorporate the order into our mass production plan and produce according to the approved sample.
5. Packing & shipping -
3
3) Do you provide samples for testing?
We can provide free samples, but the shipping cost will be borne by the customer.
-
4
4) What is your minimum order quantity?
A: 200 pieces.
-
5
5) How long does a sample order take? How about a bulk order?
Sample order: Usually within a week.
Bulk order: Usually takes 15~20 days depending on quantity and design. -
6
6) What packaging do the products use?
Plastic wrap + pearl cotton + kraft paper + cartoon box + wooden crate.
-
7
7) How do you ship the goods, and how long does it take to arrive?
We usually ship by sea / air freight/ International Express, and the arrival time depends on the distance.
-
8
8) What are your payment terms?
A: T/T 100% in advance, or other payment methods.
-
9
9) Do you provide OEM/ODM services?
Yes, we can customize.
-
9
10) Do your products have certificates?
Yes, we have ISO9001/REACH/RoSH/GS/JIS Z certifications.
