Etched 0.23~7mm Ultra-Clear AG Tempered Glass for touchscreen
Customized Specification
| Glass Material | White glass |
| Thickness | 0.23-12 mm |
| Mohs hardness | 7 |
| Tempered | Physical Tempering,Chemical Tempering |
| Edge Treatment | Flat edge, Pencil edge |
| Chamfering | Right angle, Safety angle, Round angle, Cut angle |
| Hole | Round, Squore, irregulor holes avoilable |
| Surface Coating | AG, AR, AF or customized |
| Production Process | Cutting-Edging-Cleaning-Tempered-Printing-Cleaning-Coating Inspection-Packaging |
| Sample Printing | Sample can be made based on provided samples or drawings |
| Packaging | Glass double-sided lamination & sealed box, support customized packaging |
| Certification | ROHS，GS，ISO，JIS Z |
Upgrade your visual experience with our Ultra-Clear Anti-Glare (AG) Tempered Glass, engineered for displays where clarity and comfort are critical. The specialized matte finish effectively diffuses ambient light, eliminating harsh reflections and reducing eye strain. This ensures exceptional readability and sharp image quality even in brightly lit environments, from sunny offices to outdoor public spaces.
Beyond visual comfort, our AG glass is built to last. It undergoes thermal tempering, making it significantly stronger than standard glass and highly resistant to impacts and scratches. Its smooth, low-friction surface also resists fingerprints, making it ideal for high-touch applications.
Ideal for a wide range of applications:
-
Industrial HMIs & Control Panels: Ensures operators can clearly see vital data.
-
Medical Displays & Monitors: Provides glare-free viewing for accurate diagnostics.
-
Public Information Kiosks & POS Systems: Enhances usability and durability in high-traffic areas.
-
Gaming & Retail Displays: Protects screens while improving the user experience.
Available in a versatile thickness range from 0.23mm to 7mm, we have the perfect solution to meet your specific design and durability requirements.
What is safety glass?
Tempered glass is superheated then rapidly cooled. This process, called "air-quenching," creates a strong surface compression layer and internal tension. This engineered stress balance makes it 4-5 times stronger than regular glass and causes it to break into small, granular pieces for enhanced safety.
AG Technique Parameters
Anti-glare (AG) glass features a specially etched surface that scatters reflected light. This microscopic texturing minimizes harsh reflections and glare from overhead lighting or sunlight. The result is improved visual clarity, reduced eye strain, and a matte, fingerprint-resistant finish ideal for displays and high-traffic environments.
| Item | Data |
| Gloss | 40-120 |
| Haze | 3-20 |
| Transmittance | 40%-92% |
| Roughness | 0.06-0.34 |
| Abrasion | ＞2500 Cycle |
Inspection Progress
Factory Overview
Certification
Package
Delivery & Lead Time
| Original Country | China |
| FOB Port | Shenzhen or Hongkong |
| HS Code | 700719000 |
| Lead Time | Sample within 7 days, bulk order 15~20 days |
| Delivery | By sea / DHL / Fedex / UPS |
Payment Details
1. Soda-lime Glass (Ordinary Flat Glass)
- Composition: Mainly composed of silicon dioxide (SiO₂, approximately 70%), sodium oxide (Na₂O), and calcium oxide (CaO).
- Characteristics: Easy to produce, low cost, but poor thermal stability and brittle.
- Applications: The most common type of glass, used for doors, windows, bottles, jars, and everyday utensils.
2. Borosilicate Glass (Heat-Resistant Glass)
- Composition: Based on soda-lime glass, boron oxide (B₂O₃) is added.
- Characteristics: Low coefficient of thermal expansion, high temperature resistance, resistance to rapid temperature changes (not easily cracked by sudden heating and cooling), good chemical stability.
- Applications: Laboratory instruments (such as beakers and test tubes), heat-resistant tableware (such as baking pans and glass pots), high-end flashlight lenses, etc. Well-known brands include Pyrex.
3. Aluminosilicate Glass
- Composition: Contains a large amount of aluminum oxide (Al₂O₃) and silicon dioxide (SiO₂).
- Characteristics: High hardness, scratch resistance, high mechanical strength, superior performance compared to borosilicate glass.
- Applications: Cover glass for high-end mobile phones/tablets, aviation glass, etc. Well-known brands include Corning Gorilla Glass.
4. Quartz Glass
- Composition: Silicon dioxide (SiO₂) content is above 99%.
- Characteristics: Excellent heat resistance (softening point up to 1700℃), wide light transmission spectrum (from ultraviolet to infrared), high purity, and excellent chemical stability. However, it is expensive.
- Applications: Semiconductor industry, optical devices, observation windows in high-temperature furnaces, ultraviolet lamps, etc.
To get an accurate quotation, please provide (if available):
- Product dimensions & glass thickness
- Application / usage
- Edge grinding type
- Surface treatment (coating - AG/AR/AF/AM or overlay, printing, etc.)
- Packaging requirements
- Quantity or annual usage
- Required delivery time
- Drilling or special hole requirements
- Drawings or photos
If you don't have all the details yet: just provide the information you have. Our team can discuss your requirements and help you determine specifications or suggest suitable options.
-
1
1) Are you a trading company or manufacturer?
1. Leading glass deep processing factory
2. 13 years of experience
3. OEM/ODM expertise -
2
2) How to order?
1. Your detailed requirements: drawings/quantity/or your special requirements.
2. Let's get to know each other better: We can provide your requirements.
3. Email us your formal order, payment.
4. We will incorporate the order into our mass production plan and produce according to the approved sample.
5. Packing & shipping -
3
3) Do you provide samples for testing?
We can provide free samples, but the shipping cost will be borne by the customer.
-
4
4) What is your minimum order quantity?
A: 200 pieces.
-
5
5) How long does a sample order take? How about a bulk order?
Sample order: Usually within a week.
Bulk order: Usually takes 15~20 days depending on quantity and design. -
6
6) What packaging do the products use?
Plastic wrap + pearl cotton + kraft paper + cartoon box + wooden crate.
-
7
7) How do you ship the goods, and how long does it take to arrive?
We usually ship by sea / air freight/ International Express, and the arrival time depends on the distance.
-
8
8) What are your payment terms?
A: T/T 100% in advance, or other payment methods.
-
9
9) Do you provide OEM/ODM services?
Yes, we can customize.
-
9
10) Do your products have certificates?
Yes, we have ISO9001/REACH/RoSH/GS/JIS Z certifications.
